A7 is a newly designed handheld thermal monocular with laser range finder, to meet the needs of applications such as forest fire prevention, observation and monitoring, wildlife protection, and home security at night and in adverse weather conditions. The product features a non-cooled detector and a manual focus lens, offering clear and sharp images, a compact and lightweight design, and primary functions that can be operated with a single button. It is simple and fast to use, has a robust structure, works reliably, and is easy to maintain.
Model | A7-3 | A7-6 |
Sensor | ||
Sensor | Vox | |
Resolution | 384 X 288 | 640 X 512 |
Pitch | 12μm | |
Spectrum | 8~14μm | |
NETD | ≤30mk @25°C,F#1.0 | ≤40mk @25°C,F#1.0 |
Frame rate | 50 HZ | |
Objective lens | ||
Focus | Manual | |
Lens | 35mm | 50mm |
FOV | 7.5° X 5.7° | 8.8° X 7.0° |
Zoom | 3.3 | 2.8 |
Focus length | 1m-∞ | 5m-∞ |
Detection distance | Deer：3300m
| Deer：4722m
|
Identification distance | Deer：826m
| Deer：1180m
|
LRF | ||
Laser range finder | LRF 10m~1200m (905nm) | |
Eyepiece | ||
Exit Pupil | 18mm | |
Dioptre adjustment | -5D~+5D | |
Display | ||
Type | OLED | |
Resolution | 1024×768 | |
Size | 0.39 Inch | |
Interface | ||
Language | English | |
Zoom | ×1/×2/×4/×8 | |
Mode | White hot, black hot, Fire hot, rainbow, iron red | |
Picture | Yes | |
Video | Yes | |
PIP | Yes | |
WiFi | Yes | |
CVBS | Yes | |
Hot tracking | Yes | |
Memory | ||
Storage | Built-in 16G EMMC | |
Picture/ video
| JPG/MP4 | |
USB | Export the picture and video/ recharging | |
Battery | ||
Battery | 2*18650/3200mAh | |
Working time | ≥9h | ≥9h |
Environment | ||
Operating temperature | -40℃ ~ 60℃,24H | |
Storage | -40 ℃ ~65℃ | |
Waterproof | IP65 | |
Shockproof | 1200G | |
Physical | ||
Dimension | 254*91*64.3mm | 268.9*91*64.3mm |
Weight | 893g | 967g |
